CR5MDPD12500 Overview

Huawei S16700 Series Switches CR5MDPD12500 DC Power Distribution Box.

Mappings between CR5MDPD12500 and product models

Product Product Model First Supported Version
S16700-4 EX1BS16704SD0 (02355HUM) V600R022C10
S16700-8 EX1BS16708SD0 (02355HUP) V600R022C10
Functions and Features

The power distribution box can convert 6 or 12 DC input lines into 24 output lines. It can be used in equipment room that cannot provide enough power lines.

Technical specifications of the CR5MDPD12500
Item Specification
Dimensions without packaging (H x W x D) [mm(in.)] 175 mm x 442 mm x 740 mm (6.89 in. x 17.4 in. x 29.13 in.)
Weight without packaging [kg(lb)] 30kg (66.14 lb)
Rated input voltage [V] -48 V/-60 V
Input voltage range [V] –72 V DC to –40 V DC
Rated output voltage [V] -48 V/-60 V
Maximum input current [A]
  • No copper fitting: 6 x 125 A + 6 x 125 A
  • With copper fittings: 3 x 250 A + 3 x 250 A
Maximum output current [A] 12 x 60 A + 12 x 60 A
Number of inputs
  • No copper fitting: 12
  • With copper fittings: 6
Number of outputs 24
