Huawei CE16804 Switch
Couldn't load pickup availability
CE16800 overview
The CloudEngine 16800 is the industry’s data center switch built for diversified computing power. The CloudEngine 16800 delivers stable, reliable, and high-performance Layer 2 and Layer 3 switching services, and provides customers with an intelligent, simple, secure, and open data center cloud network platform.
CloudEngine 16800 series switches use an architecture that separates the control plane, data plane, and monitoring plane. The switches use an industry-leading Clos architecture and a strict front-to-back airflow design to provide industrial-grade reliability. They support extensive data center service features. Moreover, they adopt multiple innovative energy-saving technologies to greatly reduce power consumption.
CE16804 Overview
| Item | Description | Part Number | First supported version |
|---|---|---|---|
| CE16804-AH | CE16804 AC&high-voltage DC assembly chassis | 02352RCU | V200: V200R005C20
V300: V300R020C00 |
| CE16804-DC | CE16804 DC assembly chassis | 02352RCR | V200: V200R005C20
V300: V300R020C00 |
CE16804 Appearance
Panel on the CloudEngine CE16804
| 1. PM indicator | 2. MPU indicator | 3. LPU indicator | 4. SFU indicator | 5. Fan module indicator |
| 6. Power switch | – | – | – | – |
CE16804 Datasheet
| Item | CE16804-DC |
| Chassis height [U] | 9.8 U |
| Redundant MPUs | 1:1 |
| Redundant Switch fabrics | N+M |
| Power supply mode | DC |
| Number of power modules | 6 |
| Redundant power supply |
|
| Rated input voltage [V] | -48 V/-60 V |
| Input voltage range [V] | -40 V to -72 V |
| Maximum input current [A] | 58.5 A for the voltage of -40 V |
| Maximum output power [W] |
|
| Certification |
|
| Redundant fans | Fan modules work in hot standby mode. At the normal temperature range, the system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. |
| Heat dissipation mode | Heat dissipation using fans |
| Airflow direction | Front-to-back airflow |
| Availability | 0.9999971695 |
| MTBF [year] | 34.93 year |
| MTTR [hour] | 1 hour |
| Long-term operating altitude [m (ft.)] | ≤ 5000 m (16404 ft.) (When the altitude is between 1800 m and 5000 m (5906 ft. and 16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).) |
| Long-term operating relative humidity [RH] | 5% RH to 85% RH, noncondensing |
| Long-term operating temperature [°C (°F)] | 0°C to 40°C (32°F to 104°F) |
| Storage altitude [m (ft.)] | ≤ 5000 m (16404 ft.) |
| Storage relative humidity [RH] | 5% RH to 95% RH, noncondensing |
| Storage temperature [°C (°F)] | -40ºC to +70ºC (-40°F to +158°F) |
| Dimensions with packaging (H x W x D) [mm (in.)] | 730 mm x 770 mm x 1150 mm (28.74 in. x 30.31 in. x 45.28 in.) |
| Dimensions without packaging (H x W x D) [mm (in.)] |
|
| Weight without packaging [kg (lb)] | 98.1 kg (216.31 lb) (including two MPUs and filler panels) |
| Weight without packaging (full configuration) [kg (lb)] | 163.6 kg (360.74 lb) |
| Weight with packaging [kg (lb)] | 142 kg (313.11 lb) |
| Cabinet installation standards |
|
