FAN-040B-B Overview
Huawei FAN-040B-B Fan Module (FAN panel side exhaust).
Panel of the FAN-040B-B
1. Lock |
2. Indicator |
3. Fan air vent |
4. Handle |
5. Airflow flag
|
– |
Mappings between FAN-040B-B and product models
Product | Product Model | First Supported Version | Limitations |
---|---|---|---|
CloudEngine XH8000 | XH8110-24BQ8DQ (02355YSK) | V300R023C10 | – |
CloudEngine XH8000 | XH8110-24BQ8DQ (02355YSL) | V300R023C10 | – |
CloudEngine XH8000 | XH8110-24BQ8DQ (02355YSJ) | V300R023C10 | – |
CloudEngine XH9000 | XH9110-24BQ8DQ (02355YSP) | V300R023C10 | – |
CloudEngine XH9000 | XH9110-24BQ8DQ (02355YSM) | V300R023C10 | – |
CloudEngine XH9000 | XH9110-24BQ8DQ (02355YSN) | V300R023C10 | – |
FAN-040B-B Datasheet
Item | FAN-040B-B |
---|---|
Number of fans | 1 |
Maximum power consumption [W] | 30 W |
Operating voltage range [V] | 7 V to 15 V |
Maximum fan speed [RPM] | 32000±10% |
Maximum airflow [CFM] | 40 CFM |
Maximum noise level [dB(A)] | 73 dB(A) |
Maximum wind pressure [Pa] | 1500 Pa |
Airflow direction | FAN panel side exhaust |
Automatic fan speed adjustment | After the fan module communicates normally with the switch, the switch controls the speed of the fan based on temperature of the chassis. |
Hot swapping | Supported |
Heat dissipation | Front-to-back airflow |
Dimensions without packaging (H x W x D) [mm (in.)] | 40.0 mm x 40.0 mm x 100.3 mm (1.57 in. x 1.57 in. x 3.95 in.) |
Weight without packaging [kg (lb)] | 0.1 kg (0.22 lb) |
