Huawei H902GPHF Board Overview

The H902GPHF board is a 16-port GPON interface board applied to the Huawei MA5800 series OLT MA5800-X2/MA5800-X7/MA5800-X15/MA5800-X17. It works with the optical network unit (ONU) to provide GPON access services.

The H902GPHF card will come with 16pcs C+ module by default or you can choose to come with C++/B+ module.



Technical Specifications of Huawei H902GPHF Board
Specification H901GPHF/H902GPHF H901GPSF
Application scenario FTTC/B/D, D-CCAP, FTTH, and FTTO/FTTM FTTH
Port quantity 16 16
Forwarding capability 40 Gbit/s 40 Gbit/s
Port rate Upstream: 1.244 Gbit/s Upstream: 1.244 Gbit/s
Downstream: 2.488 Gbit/s Downstream: 2.488 Gbit/s
Maximum split ratio 1: 128 1: 128
ONU-based shaping Yes Yes
Controlled optical signal transmission of the optical module Yes Yes
Temperature query and high temperature alarm Yes Yes
Automatic shutdown at high temperature Yes Yes
Energy conservation for service boards Yes Yes
Maximum distance difference between 2 ONUs under the same PON port 40 km 40 km
MAC address table size 131072 16384
Downstream FEC Yes Yes
Upstream FEC Yes Yes
Rogue ONT detection and isolation Yes Yes
Assured bandwidth 1238784 kbit/s 1238784 kbit/s
T-CONTs per GPON port 1024 1024
ONUs per GPON port 128 128
GEM ports per board 16384 16384
GEM ports per GPON port 3872 3872
Service flows per board 16368 16368
9216-byte jumbo frames Yes No
Routes/ARP table size 196608 65536
1588v2 Yes No
NTP Yes Yes
HQoS Yes No
Security (Anti-DoS, Anti-MAC/IP Spoofing) Yes Yes
Y.1731 PM Yes No
PON ISSU Yes Yes
D-CCAP Yes No
GPON type B protection (single homing) Yes Yes
GPON type B protection (dual homing) Yes No
GPON Type C protection (single homing) Yes Yes
GPON type C protection (dual homing) Yes No
Power budget per GPON port Class B+ (28.5 dB, most common),
Class C+ (32 dB, long reach transmission)
Class C++: 35 dB
Bandwidth per T-CONT 1 Mbit/s (in the minimum delay mode)
128 kbit/s (in the maximum bandwidth usage mode)



Mapping between MA5800 OLT boards and software versions
BoardName Software Versions Supported by This Board Life Cycle Status Substitution Relationship
MA5800-X17/X15/X7 MA5800-X2
Control board
H901MPLA All versions N/A N/A Replaceable with the H902MPLA board
H902MPLA V100R017C00SPC207 N/A N/A N/A
V100R017C10 and later versions
H901MPLB All versions N/A N/A N/A
H901MPSC N/A V100R017C10 and later versions N/A N/A
H901MPLE V100R019C10 and later versions N/A N/A N/A
Upstream interface board
H901NXED All versions V100R016C00SPC105 and later versions N/A Replaceable with the H901OXEG
Universal interface board
H901CIUA All versions N/A N/A Replaceable with the H902CIUA board
Power interface board
H901PILA All versions N/A N/A Replaceable with the H902PILA board
H901PISA N/A V100R017C10 and later versions N/A N/A
H901PISB N/A V100R017C10 and later versions N/A N/A
GPON interface board
H901GPHF All versions V100R016C00SPC105 and later versions N/A Replaceable with the H901CSHF/H901CGHF/H902GPHF/H902CSHF board
H901GPSF V100R016C00 and later versions V100R016C00SPC105 and later versions N/A Replaceable with the H901GPHF/H901CGHF/H901CSHF/H902GPHF/H902CSHF board
XG-PON interface board
H901XGHD All versions V100R016C00SPC105 and later versions N/A Replaceable with the H901XSHF/H902XSHD board
H901XGSF V100R016C00-V100R017C10 N/A Replaceable with the H901XSHF board
V100R018C00 and later versions
XGS-PON interface board
H901TWED V100R017C00 and later versions N/A Replaceable with the H902TWHD board
H901XSHF V100R018C00-V100R018C10 N/A N/A
V100R019C00 and later versions
H902XSHD V100R017C10-V100R019C00 N/A Replaceable with the H901XSHF board
V100R019C10 and later versions
H902TWHD V100R018C00-V100R019C00 N/A N/A
V100R019C10 and later versions
PON Combo interface board
H901CGID V100R018C00 and later versions N/A Replaceable with the H901CGHF/H902CGHD/H902CSHD board
H901CGHF V100R018C00SPH313 N/A N/A
V100R018C10SPH108
V100R019C00 and later versions
H901CSHF V100R018C00SPH313 N/A Replaceable with the H902CSHF board
V100R018C10SPH108
V100R019C00 and later versions
H902CGHD V100R018C00-V100R019C00 N/A Replaceable with the H901CGHF/H902CSHD board
V100R019C10 and later versions
H902CSHD V100R018C00-V100R019C00 N/A Replaceable with the H901CSHF/H902CSHF board
V100R019C10 and later versions
Flex-PON interface board
H901FLHF V100R019C00 and later versions N/A N/A
TDM service processing board
H901EDSH V100R016C00 and later versions V100R016C00SPC105 and later versions N/A N/A
GE/FE optical interface board
H901OGHK All versions V100R016C00SPC105 and later versions N/A N/A
10GE/GE optical interface board
H901OXHD All versions V100R016C00SPC105 and later versions N/A Replaceable with the H901OXEG board
H901OXEG V100R018C00 and later versions N/A N/A N/A
IP backhaul service board
H902CRED V100R019C00 N/A N/A N/A
V100R019C10 and later versions
FAN monitoring board
H901FMLA All versions N/A N/A N/A
H901FMMA V100R016C00 and later versions N/A N/A N/A
H901FMSA N/A V100R017C10 and later versions N/A N/A
