Dell PowerEdge R6715 Server Overview
PowerEdge R6715 system is a 1U server that supports 1, 5th Generation AMD EPYC 9005 Series processor with up to 64 Zen5 cores per processor
System Features
The PowerEdge R6715 system is a 1U server that supports:
- One 5th Generation AMD EPYC 9005 Series processor with up to 160 Zen5 cores per processor
- Up to 24x DDR5 RDIMMs (6TB max and speeds up to 5200 MT/s)
- Two redundant AC or DC power supply units
- No backplane configuration
- Up to 4 x 3.5-inch SAS/SATA drives
- Up to 8 x 2.5-inch Universal drives
- Up to 8 x U.2 drives
- Up to 10 x 2.5-inch SAS/SATA drives
- Up to 10 x 2.5-inch with 4 x Universal drives
- Up to 16 x EDSFF E3.S Gen5 NVMe drives
- Up to 20 x EDSFF E3.S Gen5 NVMe + rear 2 x EDSFF E3.S Gen5 NVMe drives
Key Workloads
The Dell PowerEdge R6715 offers powerful performance in a purpose-built, cyber resilient, mainstream server. Ideal for:
● Data Analytics
● Dense virtualization
● Software defined storage
Processor Features
The AMD EPYC™ 9005 system on a chip (SOC) is the next-generation data center CPU supporting socket compatibility with EPYC™ 9004 in SP5 + socket infrastructure. Based on of AMD's new enhanced Zen5 CPU cores with integrated I/O controllers, AMD EPYC™ "Turin" SOC offers significant performance improvement from current generation production and the best performance per price and lowers TCO through an optimal balance of compute, memory, I/O, and security.
The following lists the features and functions in the AMD Family 1 Ah Models 00h-0Fh and 10H-1FH Socket SP5 processors:
● Compute
○ Zen5 cores:
■ Up to 160 cores with 2 x threads per socket
■ Up to 256 MB L3 cache
● Memory
○ 12 DDR5 memory channels up to 5200 MT/s (1 of 2DPC) and 4400 MT/s (2 of 2DPC)
○ RDIMM
○ Dynamic PPR for non-Chipkill DIMMs
○ Up to 2 DPC capacity of 6 TB/socket
● Integrated I/O
○ Up to 128 lanes of High Speed I /O
○ Server Controller Hub (USB, UART, SPI, LPC, I2C, so on)
Storage Controllers
Dell RAID controller options offer performance improvements, including the fPERC solution. fPERC provides a base RAID HW controller without consuming a PCIe slot by using a small form factor and high-density connector to the base planar.
PERC Controller offerings are a heavy leverage of the predecessor PERC family. The Value and Value Performance levels carry over to the systems from the predecessor family.
Supported Drives
The table shown below lists the internal drives that are supported in R6715.
| Form Factor | Type | Speed | Rotational Speed | Capacities |
| 2.5 inches | SATA SSD | 6 Gbps | SSD | 480 GB, 960 GB, 1.92 TB, 3.84 TB |
| 2.5 inches | SAS HDD | 12 Gbps | 10K | 600 GB, 1.2 TB, 1.8 TB, 2.4 TB |
| 3.5 inches | SATA HDD | 6 Gbps | 7.2K | 2 TB, 4 TB, 8 TB, 12 TB, 16 TB, 20 TB, 24 TB, 32 TB* |
| 3.5 inches | SAS HDD | 12 Gbps | 7.2K | 4 TB, 8 TB, 12 TB, 16 TB, 20 TB, 24 TB, 32 TB* |
| 2.5 inches | NVMe | Gen5 | SSD | 1.92 TB, 3.84 TB, 7.68 TB, 15.36 TB, 30.72 TB, 61.44 TB |
| EDSFF E3.S NVMe | NVMe | Gen5 | SSD | 1.6 TB, 1.92 TB, 3.2 TB, 3.84 TB, 6.4 TB, 7.68 TB, 15.36 TB, 30.72 TB, 61.44 TB |
Technical Specifications of Dell PowerEdge R6715 Server
| Category | Specification |
| Server Model | Dell PowerEdge R6715 |
| Chassis | 1U Rack Server |
| CPU Support | 1 × 5th Generation AMD EPYC 9005 Series Processor |
| Max Core | Up to 160 Zen5 cores per processor |
| Max TDP | Up to 400W |
| Socket | AMD SP5 Socket |
| Chipset | AMD Chipset |
| Memory Type | DDR5 RDIMM ECC |
| DIMM Slots | 24 × DDR5 DIMM slots |
| Memory Channels | 12 channels per CPU |
| Max Memory Capacity | Up to 6TB |
| Memory Speed | Up to 5200 MT/s (depending on CPU/DIMM configuration) |
| Front Storage Options | 4×3.5" SAS/SATA HDD; 8×2.5" Universal SSD; 8×U.2 NVMe; 10×2.5" SAS/SATA; 16×EDSFF E3.S Gen5 NVMe |
| Rear Storage | Up to 2×EDSFF E3.S Gen5 NVMe |
| RAID Controller | PERC H365i / H965i / H975i |
| HBA | HBA465e / H965e |
| Boot Device | BOSS-N1 DC-MHS |
| OCP Support | OCP 3.0 |
| OCP PCIe Generation | PCIe Gen5 |
| Max Network Speed | Up to 400GbE |
| OCP Ports | Up to 4 ports |
| Expansion Slots | Up to 3 × PCIe Gen5 x16 slots |
| Accelerator Support | Up to 3 × 75W GPUs |
| Power Supply Options | 1800W / 1500W / 1400W / 1100W / 800W |
| Redundancy | Hot-plug redundant PSU |
| Cooling Type | Air Cooling / Direct Liquid Cooling |
| Fan Redundancy | N+1 fan redundancy |
| Remote Management | iDRAC10 Enterprise / Datacenter |
| Management Tools | OpenManage Enterprise, Redfish API, RACADM CLI |
| Security Features | Secure Boot, Silicon Root of Trust, Secure Erase, TPM 2.0 |
| Operating Systems | VMware ESXi, Windows Server Hyper-V, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu Server LTS |
| Height | 42.8 mm (1.68") |
| Width | 482 mm (18.97") |
| Depth | 816.921 mm (32.16") with bezel |
| Maximum Weight | Up to 21.19 kg depending configuration |
