Dell PowerEdge R760xs Server Overview
The Dell PowerEdge R760xs is Dell’s latest two-socket, rack server that is designed to run complex workloads using highly scalable memory, I/O, and network options. The systems feature the 4thand 5th Gen Intel® Xeon® Scalable Processor (Socket E1/LGA4677-1), up to 16 DIMMs, PCI Express® (PCIe) 5.0 enabled expansion slots , and a broad selection of network interface technologies.
The Dell PowerEdge R760xs is the best choice for the right balance in performance in an air-cooled chassis for the most popular IT applications.
System Features
- Add up to two 5th Generation Intel® Xeon® Scalable processors with up to 28 cores per socket for faster performance
- Accelerate in-memory workloads with up to 16 DDR5 RDIMMS up to 5200 MT/sec
- Improve data throughput and reduce latency with support up to 8 I/O devices
- Up to 6 PCIe slots, 1 OCP 3.0 networking slot, and 1 dedicated PERC slot
- Storage options include up to 12 x 3.5” HDDs/SSDs; or up to 16 x 2.5” HDD/SSDs, plus up to 8 x NVMe drives
Key Workloads
The target workloads for the PowerEdge R760xs include virtualization, medium density VM and VDI, and scale-out database. .
Processor Features
The Intel 4th and 5th Generation Xeon® Scalable Processors stack is the next-generation data center processor offering with
significant performance increases, integrated acceleration, and next-generation memory and I/O. Sapphire Rapids and Emerald
Rapids accelerate customer usage with unique workload optimizations and provide the following feature improvements.
● Faster UPI with up to three Intel Ultra Path Interconnect (Intel UPI) at up to 20 GT/s, increasing multisocket bandwidth.
● More, faster I/O with PCI Express 5 and up to 80 lanes (per CPU)
● Enhanced Memory Performance with DDR5 support and memory speed up to 5200 MT/s in one DIMM per channel (1DPC).
● New onboard accelerators for data analytics, networking, storage, crypto, and data compression
● Enhanced security for virtualized environments with Intel Trust Domain Extensions (IntelR TDX) for confidential computing
Storage Controllers
Dell RAID controller options offer performance improvements, including the fPERC solution. fPERC provides a base RAID HW controller without consuming a PCIe slot by using a small form factor and high-density connector to the base planar.
16G PERC Controller offerings are a heavy leverage of 15G PERC family. The Value and Value Performance levels carry over to 16G from 15G. New to 16G is the Avenger-based Premium Performance tier offering. This high-end offering drives IOPs performance and enhanced SSD performance.
Supported Drives
The table shown below lists the internal drives that are supported in R760xs.
| Form Factor | Type | Speed | Rotational Speed | Capacities |
| 2.5 inches | vSAS | 12 Gb | SSD | 1.92 TB, 3.84 TB, 960 GB, 7.62 TB |
| 2.5 inches | SAS | 24 Gb | SSD | 1.92 TB, 1.6 TB, 800 GB, 3.84 TB, 960 GB, 7.68 TB |
| 2.5 inches | SATA | 6 Gb | SSD | 1.92 TB, 480 GB, 960 GB, 3.84 TB |
| 2.5 inches | NVMe | Gen4 | SSD | 1.6 TB, 3.2 TB, 6.4 TB, 1.92 TB, 3.84 TB, 15.63 TB, 7.68 TB |
| 2.5 inches | DC NVMe | Gen4 | SSD | 3.84 TB, 960 GB |
| 2.5 inches | SAS | 12 Gb | 10 K | 600 GB, 1.2 TB, 2.4 TB |
| 3.5 inches | SATA | 6 Gb | 7.2 K | 2 TB, 4 TB, 8 TB, 12 TB, 16 TB, 20 TB, 24 TB |
| 3.5 inches | SAS | 12 Gb | 7.2 K | 2 TB, 4 TB, 8 TB, 12 TB, 16 TB, 20 TB, 24 TB |
Technical Specifications of Dell PowerEdge R760xs Server
| Category | Specification |
| Server Model | Dell PowerEdge R760xs |
| Form Factor | 2U Rack Server |
| Processor | Up to 2 × Intel Xeon Scalable (4th/5th Gen), up to 32/28 cores |
| Chipset | Intel C741 |
| Operating System | Windows Server, RHEL, SUSE, VMware ESXi, Ubuntu |
| Memory Type | DDR5 RDIMM |
| DIMM Slots | 16 |
| Max Memory | 1.5TB |
| Memory Speed | Up to 5200 MT/s |
| Front Drive Bays | Up to 8×3.5", 12×3.5", 8×2.5", 16×2.5", 16×2.5"+8×NVMe |
| Rear Drive Bays | Up to 2×2.5" SAS/SATA/NVMe |
| RAID Controller | PERC H965i / H755 / H755N / H355 / HBA355i |
| External Controller | HBA355e |
| Software RAID | S160 |
| Boot | BOSS-N1 (2×M.2 NVMe) |
| PCIe Slots | Up to 6 PCIe (Gen4/Gen5) |
| Network | 2×1GbE LOM / OCP 3.0 |
| GPU | 2×75W Low Profile |
| Power Supply | 600W / 700W / 800W / 1100W / 1400W / 1800W |
| Fans | Up to 6 Hot-plug Fans |
| Front Ports | USB, VGA, iDRAC Direct |
| Rear Ports | USB2.0, USB3.0, VGA, Serial, iDRAC |
| Internal Port | USB3.0 |
| Management | iDRAC9, OpenManage, CloudIQ, Redfish |
| Security | TPM2.0, Secure Boot, Silicon Root of Trust |
| Dimensions | 86.8 × 482 × 707.8 mm |
| Weight | Max 28.6 kg |
| Rack Rails | Sliding Rails With Cable Management Arm |
| Warranty | 3 year global warranty |
