CE6855-48T6Q-HI Hardware Description
Introduction
Ports on the CE6855-48T6Q-HI
Attribute |
Description |
---|---|
Connector type |
RJ45 |
Standards compliance |
IEEE802.3an and IEEE802.3az |
Applicable cable |
Straight-through cable and crossover cable |
Working mode |
Supported rate: 100/1000 Mbit/s and 10 Gbit/s auto-sensing Full-duplex |
Maximum transmission distance |
100 m |
Attribute |
Description |
---|---|
Connector type |
LC/MPO |
Optical port attributes |
Depending on the module or cable in use |
Standards compliance |
IEEE802.3ba |
Working mode |
Full-duplex |
Technical specifications of the CE6855-48T6Q-HI
Item |
Description |
|
---|---|---|
Physical specifications |
|
|
Environment parameters |
Temperature |
|
Relative humidity |
5% RH to 95% RH, noncondensing |
|
Altitude |
< 5000 m (16404 ft.) |
|
Noise (sound pressure, 27°C) |
|
|
Power specifications |
Power source type |
AC/DC/high-voltage DC |
AC power input |
|
|
DC power input |
|
|
High-voltage DC power input |
|
|
Rated input current |
|
|
Chassis power consumption |
Maximum power consumption |
346 W |
Typical power consumption |
219 W (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
|
Chassis heat dissipation |
Maximum heat dissipation |
1181 BTU/hr |
Typical heat dissipation |
747 BTU/hr (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
|
Surge protection |
Ethernet electrical ports: 2 kV in common mode Power module:
|
|
Heat dissipation |
Heat dissipation mode |
Air cooling |
Airflow |
Front-to-back or back-to-front, depending on the fan modules and power modules |
|
Reliability and availability |
Power module backup |
1+1 backup |
Fan module backup |
1+1 backup not supported NOTE:
A CE6800 chassis uses two fan modules, with each fan module containing two fans. The four fans in the chassis work in 3+1 backup mode. |
|
Hot swap |
Supported by all power modules and fan modules |
|
Mean time between failures (MTBF) |
54.48 years |
|
Mean time to repair (MTTR) |
1.81 hours |
|
Availability |
0.99999620929 |
|
Technical specifications |
Processor |
1.2 GHz, quad-core |
DRAM Memory |
2 GB |
|
NOR Flash |
16 MB |
|
NAND Flash |
1 GB |
|
Stack |
Service port supporting the stack function |
10GE electrical ports and 40GE optical ports |
Certification |
|
