Huawei EG8145X6 ONT

$0.00
$0.00
Power Adapter: EU Standard
Availability: 8000 in stock
Tags:
Collections:
$0.00
$0.00
Huawei EG8145X6 ONT Overview



Introduction

EG8145X6 is an intelligent Wi-Fi 6 routing optical network terminal (ONT) that uses Gigabit Passive Optical Network (GPON) technology to provide users with ultra-broadband access, high performance, and wide coverage. OptiXstar EG8145X6 relies on high forwarding performance to ensure an excellent experience for voice, data, and high-definition video services, as well as future-oriented business support capabilities and visual network management, helping enterprises build powerful all-optical access solutions.


Key Feature
  • Provide 4GE, 2USB and 1POTS, 2.4G&5G WiFi 6
  • IGMP v2/v3 snooping, IGMP v2/v3 proxy, MLD v1/v2 snooping
  • Network port rate limit, 802.1p priority, SP/WRR/SP+WRR broadcast, packet rate limit
  • PPPoE/static IP/DHCP, NAT/NAPT, port forwarding, ALG, UPnP, DDNS/DNS server/DNS client
  • IPv6/IPv4 dual stack and DS-Lite, static/default routing, multiple services on one WAN port

Device Parameters
Basic Parameters
Ports 1 x POTS + 4 x GE + 2.4G/5G 11ax Wi-Fi + 2 x USB
SC/UPC GPON
Working environment Operating temperature: 0ºC to 40ºC
Environment humidity: 5% to 95% (noncondensing)
Static power consumption 5.3 W
Max. power consumption 18 W
Power specifications Power adapter input: 100 to 240 V AC, 50–60 Hz
System power supply: 11–14 V DC, 1.5 A
WLAN

2.4GHZ: 802.11n

5GHZ: 802.11ax
Network-side Port GPON/EPON
Indicators POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB
GPON Port • Class B+
• Receiver sensitivity: –27 dBm to –29 dB
• Overload optical power: –8 dBm
• Wavelengths: US 1310 nm, DS 1490 nm
• Wavelength Blocking Filter (WBF) of G.984.5
• Flexible mapping between the GEM port and TCONT
• GPON: consistent with the SN or password authentication defined in G.984.3
• Bi-directional FEC
• SR-DBA and NSR-DBA
• Type B (single-homing and dual-homing)
WLAN • IEEE 802.11 b/g/n/ax (2.4G)
• IEEE 802.11 a/n/ac/ax (5G)
• 2 x 2 MIMO (2.4G)
• 2 x 2 MIMO (5G)
• Antenna gain: 5 dBi
• WMM/Multiple SSIDs/WPS
• 2.4G and 5G concurrency
• Air interface rate: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G)
• Beamforming
• Band steering
• DL OFDMA
• DL MU-MIMO
• 1024 QAM
• 160 MHz frequency bandwidth
• WPA3
Dimensions
(length x width x height)		 195 mm x 125 mm x 35 mm
Weight About 370 g
Common O&M • OMCI/Web UI/TR069
• Variable-length OMCI messages
• Dual-system software backup and rollback
